KZ Venom Toy Hauler Fifth Wheel
If you are looking for comfort and luxury along with style as you travel with your off-road toys, then choose the Venom toy hauler fifth wheel by KZ. These luxury toy hauler fifth wheels have all of the conveniences you know and love, plus a few extra luxuries you won't believe!
Starting with the exterior, you are sure to appreciate the 8'5" wide body construction, 6-sided aluminum frame, Superflex roof membrane, and the radius, aerodynamic, fully-painted, extra-reinforced, and heavy-duty front fiberglass cap with LED accent lights. Plus there is a 40 gallon fuel station with electric pump to keep the fun going all weekend long.
There are several luxurious features found inside each model that will make you want to choose a Venom toy hauler fifth wheel by KZ today!
-
Venom V3411TK
KZ Venom toy hauler V3411TK highlights: 11' Cargo Area Triple Theater Seats Loft ... more about Venom V3411TK
Specifications
Sleeps 7 Slides 3 Length 37 ft 8 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 2520 lbs Gross Weight 16000 lbs Dry Weight 13300 lbs Cargo Weight 2700 lbs Fresh Water Capacity 112 gals Grey Water Capacity 57 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 10780 lbs Garage Size 11 ft LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric DSI AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 18' LCI Smart Arm with Light Strip, Optional 10' Axle Count 2 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V3911TK
KZ Venom toy hauler V3911TK highlights: L-Shaped Sofa Free Standing Table Dual ... more about Venom V3911TK
Have a question about this floorplan? Contact Us
Specifications
Sleeps 8 Slides 3 Length 42 ft 7 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 3070 lbs Gross Weight 19000 lbs Dry Weight 14050 lbs Cargo Weight 4950 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 10980 lbs Garage Size 11 ft LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 17' LCI Smart Arm with Light Strip, Optional 11' Axle Count 3 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V4012TK
KZ Venom toy hauler V4012TK highlights: Hide-A-Bed Sofa U-Shaped Counter Bath ... more about Venom V4012TK
Have a question about this floorplan? Contact Us
Specifications
Sleeps 7 Slides 3 Length 43 ft 7 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 3190 lbs Gross Weight 19000 lbs Dry Weight 15310 lbs Cargo Weight 3690 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 12120 lbs Garage Size 12 ft LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV, Ext. TV Awning Info 15' LCI Smart Arm with Light Strip, Optional 16' Axle Count 3 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V4013TK
KZ Venom toy hauler V4013TK highlights: 13' Cargo Area Removable Tables Kitchen ... more about Venom V4013TK
Specifications
Sleeps 7 Slides 3 Length 43 ft 4 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 5 in Interior Color Nighthawk, Sandstorm Hitch Weight 3100 lbs Gross Weight 19000 lbs Dry Weight 15100 lbs Cargo Weight 3900 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 77 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 12000 lbs Garage Size 13 ft LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 17' LCI Smart Arm with Light Strip, Optional 11' Axle Count 2 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V4111TK
KZ Venom toy hauler V4111TK highlights: Bath and a Half Free Standing Table Loft ... more about Venom V4111TK
Specifications
Sleeps 9 Slides 3 Length 43 ft 4 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 3160 lbs Gross Weight 19000 lbs Dry Weight 14700 lbs Cargo Weight 4300 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 11540 lbs Garage Size 13 ft 11 in LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 15' LCI Smart Arm with Light Strip, Optional 15' Axle Count 3 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V4113TK
KZ Venom toy hauler V4113TK highlights: Patio Deck Dual Entry 40" Loft Bed Bath ... more about Venom V4113TK
Have a question about this floorplan? Contact Us
Specifications
Sleeps 7 Slides 3 Length 43 ft 7 in Ext Width 8 ft 6 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 2820 lbs Gross Weight 19000 lbs Dry Weight 15160 lbs Cargo Weight 3840 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 12340 lbs Garage Size 13 ft LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 14' LCI Smart Arm with Light Strip, Optional 18' Axle Count 3 Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
-
Venom V4114TK
KZ Venom toy hauler V4114TK highlights: Free Standing Table Loft Bed L-Shaped ... more about Venom V4114TK
Have a question about this floorplan? Contact Us
Specifications
Sleeps 8 Slides 3 Length 43 ft 4 in Ext Width 8 ft 5 in Ext Height 13 ft 4 in Int Height 8 ft 6 in Interior Color Nighthawk, Sandstorm Hitch Weight 3130 lbs Gross Weight 19000 lbs Dry Weight 14400 lbs Cargo Weight 4600 lbs Fresh Water Capacity 112 gals Grey Water Capacity 97 gals Black Water Capacity 57 gals Tire Size 16" Furnace BTU 35000 btu Fuel Capacity 40 gals Number Of Bunks 1 Available Beds Queen Refrigerator Size 8 cu ft Cooktop Burners 3 Number of Awnings 2 Axle Weight 11270 lbs Garage Size 13 ft 10 in LP Tank Capacity 30 lbs. Water Heater Capacity 12 gal. Water Heater Type Gas/Electric AC BTU 15000 btu TV Info Garage TV, LR TV, BR TV Awning Info 15' LCI Smart Arm with Light Strip, Optional 15' Axle Count 3 Washer/Dryer Available Yes Number of LP Tanks 2 Shower Type Shower w/Seat Electrical Service 50 amp Similar Floorplans
Venom Features:
Standard Features
Construction
- 101" Wide Body Construction
- 6-Sided aluminum frame, including welded aluminum fore & aft floor joists, sidewall framing, & roof trusses
- Extra Reinforced Heavy-Duty Front Fiberglass Cap
- Radius Aerodynamic Front Cap
- 2" x 3" Fully-Welded Aluminum Floor Framing
- 2" x 2" Fully-Welded Aluminum Sidewall Framing
- 5" Welded Aluminum Roof Trusses
- Lippert® Hydraulic Slide System w/Selector Valves
- 12" Powder-Coated Steel I-Beam w/Drop Frame (160 SQ FT Pass-Thru Storage)
- Lamilux 4000® High-Gloss Fiberglass Sidewalls
- All Weather Insulation Package to R38 (roof, floor, garage floor end caps, holding tanks)
- Double Insulated & Heated Holding Tanks (R38 above & below tanks)
- Additional Outside Frame-to-Wall Floor Insulation
- R11 2" Sidewalls (w/EGS metal backing strips)
- One-Piece ABS Slideroom Bottoms
- Superflex® Roof Membrane (TPO/Rubber Hybrid, 12-year warranty)
- 45-Degree Radius Aluminum Roof Edge
- Fully Vented Attic System
- 3/8" Fully Walk-On Roof Decking
- 5/8" Tongue & Groove Screwed & Glued Plywood Floor Decking
- Metal Skirt (covering the door side frame)
- Pex® In-Floor Heated Waterlines & Kitchen Gray Pipes (all waterlines & drains located above all insulation)
- Fully-Enclosed & Heated Underbelly w/Direct-Heated Holding Tanks
Exterior
- 7,000 LB Dexter® Axles w/Auto Adjusting Brakes & Height Adjusting Hangers
- 8-Lug Heavy-Duty Aluminum Rims w/16" E-Range Radial Tires
- EZ Flex® Rubberized Suspension
- Aluminum 4-Step Entry w/LED Light
- Roto-Flex® Hitch Pin
- 100% Exterior LED Running & Taillights
- LCI Smart Arm Awning w/Light Strip
- Propane Bottles (2 X 30 lbs.) on Same Side for Easy Access
- Sealed Battery Storage Compartment (no battery boxes required)
- Triple Front Slam-Latch Baggage Doors
- Side Slam-Latch Baggage Doors w/Gas Struts & Dual Locks
- 50 AMP Service w/Detachable Marine Power Cord
- Fully Painted Front Cap w/LED Accent Lights
- Frameless Windows
- 15,000 BTU Ducted Roof AC w/Quiet Cool (prewired for OPT ducted 15,000 BTU bedroom AC w/quiet cool)
- Wired & Framed for OPT 3rd 15,000 BTU AC
- 35,000 BTU Furnace w/3" x 14" In-Floor Straight Line Heating System
- 12 GAL Gas/Electric Hot Water Heater
- LED Entry Door Floodlight
- Ramp Door w/LED Lighting
- LED Docking & Sewer Hookup Lights
- Sewer Hose Storage Tube
- Dual Swing-Away Assist Grab Handle
- Under-Frame Spare Tire w/Hoist
- Roof Ladder
- Heated Water Convenience Center (incl. black tank flush, power fresh tank water fill, winterizing system, outside shower, & dry-camping water siphon)
- Fully-Finished Heated & Sealed Basement Storage Compartment
- Camp Table & Patio Chairs Storage Compartment
- Heated & Enclosed Dump Valves
- Battery Disconnect
- Satellite Pre-Wire in Convenience Center & Roof
- LED Lighted Outside Speakers
- Generator Prep w/Surge Protector & Dedicated 30 GAL Fuel Tank
- 40 GAL Fuel Station w/Electric Pump
- Solar Prep - Roof
- LP Quick Connect
- Rear Camera Prep
- Keyed Alike Baggage Doors
Kitchen
- Solid Surface Countertops, Flush-Mount Stove Covers & Sink Covers w/Large Handholds
- Large Residential Double Bowl Stainless Steel Sink
- High-Arching, Pullout, Residential Faucet
- 30" Microwave above Range
- U.S. Made Large Dining Table w/Removable Leaf & 2 Heavy-Duty Chairs (2 additional folding chairs V3911TK, V411TK, V4114TK)
- Power Vent Kitchen Fan w/Wall Controls
- XL Residential Size Pullout Trashcan (where applicable)
- Removable Silverware Tray
- Under-Sink Storage Shelf
- OH Cabinets incl. Shelf & Extra-Tall Slide Lips
- Hidden Cabinet Door Hinges
- 5" Stainless Steel Cabinet Hardware
- Baltic Birch Drawer Boxes
- Heavy-Duty 100 LB Drawer Glides
- LED Kitchen Cabinet Toe-Kicks (where applicable)
- Kitchen Window (most models)
Interior
- 7" Monitor MyRV® Control Panel (monitors tank levels & battery levels, controls slide rooms, leveling system, awnings, inside/outside lighting)
- 22 OZ Residential Carpet w/3/8" Re-bond Padding
- XL Ceiling Crown Molding
- Night Roller Shades Throughout
- 100% LED Ceiling & Cabinet Lights w/Multiple On/Off Switches
- LED RGB Entertainment Lights
- Extra-Large Light Switches
- Faux Vinyl Soft Touch Ceiling
- Deluxe Residential - Style Furniture
- Removable Pedestal Tables in Front of Seating (based on model)
- 40" - 48" HD LED TV on Swing Arm w/Behind - TV Storage
- Residential Entertainment System w/Radio/Bluetooth/Sound Bar & Bass Subwoofer
- USB Charging Station & 12V Power Outlet
- 40" Wide View Fireplace w/Remote (most models)
Bedroom
- XL Deep Closet w/Shoe Storage Rack (V3911TK, V4013TK)
- Dual Washer/Dryer Prep (stacked or side-by-side)
- XL Under-Bed Storage
- Luxurious Bedspread & Pillow Shams
- Flat Panel TV on Swing Arm
- 60" x 80" Queen-Size Upgraded Mattress
- Motion Light - Closet
Bath
- Residential One-Piece FG Shower Stall w/Glass Doors & Built-In Seat
- Shower Skylight
- XL Solid Surface Bath Vanity w/Stainless Steel Sink
- Motion Light
- Porcelain Foot-Flush Toilet
- XL Linen Cabinet
- XL Deep Closet w/Shoe Storage Rack (V3911TK & V4013TK)
- Extra-Wide Hallway & Pocket Door
- Power Vent w/Wall Switch
- Towel Bar & Towel Ring
Garage
- Roll-Down Screen Wall
- E-Track Tie-Down System
- Built-In Dovetail
- 24" Diamond Plate Wall Guards
- Garage Entry Door
- HD Flat Panel Garage TV on Swing Arm
- 12V Radio/DVD Player
- (2) Garage Ceiling Speakers
- Speaker On/Off Switches
- Zero Gravity Ramp Door with Easy Lift Assist
Options
Exterior
- 6-Point Hydraulic Auto Leveling System
- 2nd Lighted Power Garage Entry Door Awning
- Dual Pane Frameless Windows
- Onan® 5500 Gas Generator
- 15,000 BTU Bedroom AC
- 15,000 BTU Garage AC w/Load Management System
- Slideout Cover Package
- Backup Camera
- "Off the Grid" Package (includes 160W Solar Panel, Inverter and Monitor)
- Trail Air Flex Air Upgrade Pinbox
- MORryde Flip Out Steps (main entrance only)
- Full-Body Paint Package
Interior
- Theater Seat IPO Free-Standing Table & Chairs (V3911TK, V4111TK, V4114TK)
- 18 CU FT 120V Residential Refrigerator w/Inverter (N/A V3411TK, V4013TK, V4113TK)
- 18 CU FT 4-Door RV Refrigerator (LP/Electric)
- 30" OTR Convection Oven/Microwave IPO OTR Microwave
- Power Vent Fan w/Wall Controls (bath, bedroom, garage)
- Day/Night Roller Shades
- Central Vacuum System
Bedroom
- 72" x 80" King Size Upgraded Mattress
Garage
- HappiJac® Electric Bed & Rollover Sofa w/Table
- Ramp Door Patio w/Entry Steps & w/Electric Awning
- 3-Season Patio Door IPO Roll-Down Screen Wall
- Toy Lock
- Removable Edged Garage Carpet Kit 10' x 8'
See us for a complete list of features, available options and warranty info!
All features and specifications are subject to change.
Manu-Facts:
K.Z. Inc., a subsidiary of Thor Industries Inc., is headquartered in Shipshewana, Indiana, and was founded in 1972. We have been earning our reputation as an outstanding recreational vehicle manufacturer – largely through our commitment to quality and our attention to meeting the unique needs of customers like you.
Our mission is to continue to strive for the highest quality in our products and services, to develop new concepts and competitively priced products; applying courtesy, integrity and fairness in dealing with our customers.
